no-iso

RightMark Audio Analyzer test


Testing chain: without iso transformer
Sampling mode: 16-bit, 44 kHz




Summary

Frequency response (from 40 Hz to 15 kHz), dB: +0.07, -0.44Good
Noise level, dB (A): -93.4Very good
Dynamic range, dB (A): 93.4Very good
THD, %: 0.010Good
IMD, %: 0.012Very good
Stereo crosstalk, dB: -89.7Excellent
IMD at 10 kHz, %: 0.019Very good

General performance: Very good




Frequency response

Spectrum graph


Frequency range Response
From 20 Hz to 20 kHz, dB-0.73, +0.07
From 40 Hz to 15 kHz, dB-0.44, +0.07




Noise level

Spectrum graph


Parameter Left Right
RMS power, dB:-91.5-91.5
RMS power (A-weighted), dB:-93.4-93.3
Peak level, dB FS:-64.0-64.0
DC offset, %:-0.00-0.00




Dynamic range

Spectrum graph


Parameter Left Right
Dynamic range, dB:+91.7+91.8
Dynamic range (A-weighted), dB:+93.4+93.4
DC offset, %:-0.00-0.00




THD + Noise (at -3 dB FS)

Spectrum graph


Parameter Left Right
THD, %:0.01060.0104
THD + Noise, %:0.01190.0118
THD + Noise (A-weighted), %:0.01460.0144




Intermodulation distortion

Spectrum graph


Parameter Left Right
IMD + Noise, %:0.01180.0118
IMD + Noise (A-weighted), %:0.00840.0087




Stereo crosstalk

Spectrum graph


Parameter L <- R L -> R
Crosstalk at 100 Hz, dB:-86-90
Crosstalk at 1 kHz, dB:-79-89
Crosstalk at 10 kHz, dB:-60-73




IMD (swept tones)

Spectrum graph


Parameter Left Right
IMD + Noise at 5 kHz, %:0.01530.0151
IMD + Noise at 10 kHz, %:0.01860.0186
IMD + Noise at 15 kHz, %:0.02290.0234

This report was generated by RightMark Audio Analyzer 5.4
